LINK G4+ Storm -JAPRACE-

LINK G4+ Storm -JAPRACE-

$1,949.25

Welcome to Japanese Race Supplies!

G4+ STORM ECU

If it is value for money you are after, the Storm is the ECU for you. The Storm offers most of the advanced G4+ tuning features, at an extremely competitive price.
The Storm has more inputs (digital, analogue and temp), as well as more outputs than the Atom and Monsoon. Its 8 Injector drives and 8 ignition drives allows sequential injection and direct spark on engines up to 8 cylinders.

If it is Traction control, e-throttle or Peak and Hold injection you are after, consider an Xtreme or Fury.

Inputs

8 x Digital inputs
3 x temperature inputs
8 x Analog inputs
2 x Trigger Inputs
2 x Knock Inputs

Outputs

8 x Injection drives
8 x Ignition drivers
8 x Auxiliary outputs*
+5V Sensor power supply
+8V Sensor power supply


Advanced features not found on the Atom or Monsoon

-Built in trigger oscilloscope.
-Onboard Knock Control – support for two knock sensors wired directly to the ECU. No external amplifier required.
-Boost control can be open or closed loop with up to three switchable tables.
-Idle valve solenoid or stepper motor control.
-Rotary oil metering pump control.

Most Motorsport features including full gear shift control, antilag and launch control

Up to 4 fully variable closed loop VVT cams. (up from 2)



What’s in the box

Supplied with USB tuning cable and mounting bracket.

Requires “A” & “B” looms or “A” & “B” connector kits (not supplied)
